Product Summary
The MP1583DN-LF-Z is a monolithic step down switch mode converter with a built ininternal Power MOSFET. The MP1583DN-LF-Z achieves 2A continuous output current over a wide input supply range with excellent loadand line regulation. Current mode operation provides fast transient response and eases loop stabilization. Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown.
Parametrics
MP1583DN-LF-Z absolute maximum ratings: (1)Supply Voltage (VVIN): 28V; (2)Switch Voltage (VSW): -1V to VIN +1V; (3)Boost Voltage VSW+ 6V; (4)Feedback Voltage (VFB): -0.3 to 6V; (5)EN/UVLO Voltage (VEN): -0.3 to 6V; (6)COMP Voltage (VCOMP): -0.3 to 6V; (7)Sync Voltage (VSync): -0.3 to 6V.
Features
MP1583DN-LF-Z features: (1)converter; (2)28V rated voltage; (3)2A rated current.
