Product Summary
The IMP810REUR-T is a 3.0V, 3.3V and 5.0V power supply supervisor cir-cuits optimized for low-power microprocessor (μP), microcontroller (μC) and digital systems. The IMP810REUR-T is improved drop-in replacements for the Maxim MAX809/810 and feature 60% lower supply current. A reset signal is issued if the power supply voltage drops below a preset reset threshold and is asserted for at least 140ms after the supply has risen above the reset threshold. The applications of the IMP810REUR-T include Embedded controllers, Battery operated systems, Intelligent instruments, Wireless communication systems, PDAs and handheld equipment.
Parametrics
IMP810REUR-T absolute maximum ratings: (1)VCC: -0.3V to 6.0V; (2)RESET, RESET: -0.3V to (VCC+ 0.3V); (3)Input Current at VCC: 20mA; (4)Output Current: RESET, RESET: 20mA; (5)Rate of Rise at VCC: 100V/μs; (6)Power Dissipation (TA= 70℃): 320mW (Derate 4mW/℃ above 70℃); (7)Operating Temperature Range: -40℃ to 105℃; (8)Storage Temperature Range: -65℃ to 160℃; (9)Lead Temperature (soldering, 10 sec): 300℃.
Features
IMP810REUR-T features: (1)Improved Maxim MAX809/MAX810 replacement, Lower supply current: 6μA; 80% lower maximum supply current; (2)Monitor 5V, 3.3V and 3V supplies; (3)140ms min. reset pulse width; (4)Active-low reset valid with 1.1V supply (IMP809); (5)Small 3-pin SOT-23 package; (6)No external components; (7)Specified over full temperature range: -40℃ to 105℃.
Diagrams
 |
